Robot structural design 15 stories residential buildings

Analysis and design of 15 stories and one basement R.C Building on Robot software including earthquake design + Pool

What you will learn

Structural design of R.C building from A to Z included all structural element (columns, beams, slabs, foundations, shear walls, check deflection, how we can determine the dimensions of the elements)


This course not just a tutorial on Robot software but it is a complete understanding about structural design analysis, how civil engineer must begin with the project, how he/she must think, how we can determine the dimension of the element before modeling them check it in the software. In this course we will design a 15 stories of a residential buildings, within the work we will define and design all types of slabs such as (waffle slab, one way ribbed slab, two way ribbed slab, flat slab and solid slab), foundations, earthquake loads, columns and beams and shear walls + design a swimming pool in Robot




Introduction part1 description of the project
Introduction part 2 waffle slab type 1 definition and thickness determination
Introduction Part 2 Definition of Waffle slab types2 and thickness determination
Introduction part 2 One Way Ribbed Slab
Introduction part 2 Flat Slab
Introduction part 2 solid slab definition and thickness determination

Robot software

Define units and grids
Modeling of the project
Assign slabs sections
Loads, mesh, and design (column, beams, slabs, walls and foundation)
Define earthquake loads in Robot

Swimming Pool structural design

Swimming Pool structural design
Define all types of grids
Draw circular beams and slabs in Robot

Thank you

Thank you
