Read Construction & Structural Drawings Like An Expert



Full Course on Structural Drawings From Basic to Advance

What you will learn

Learn to Read Structural Drawings of Commercial Buildings ( B+G+32 Buildings )

What Is Structural Drawings & Its Importance in Construction

Structural Drawings of Foundation and Its Component

Structural Drawings of Column from Foundation to Top Floor

Structural Drawings of Beam & Slabs with All Details

Structural Drawings of Stairs & Lift in Building

Description

About This Project :

Project is located on a 23270 sqm (5.75 Acre) plot in Sec.- KP-IV. Project comprises of two low rise structures and two high rise towers with the one basement levels as detailed below-

• G+32 storey tower =1 No.
• G+22 storey tower = 1 No.
• G+4 storey Administrative Block = 1 No.
• G+1 Convention Block = 1 No.
• Basement = 1 level

Total Ground Coverage is 6834 sqm and Total Built-up area of all floors are 88000 Sqm. Building is designed on the basis of Green Building Concept and also to achieve a LEEDS platinum rating. Structure has been designed as a RCC framed structure and type of foundation is Raft Foundation. Parking facility is provided in a basement and at stilt level. Offices of the various department are housed in two high-rise towers. The Administration & Auditorium blocks are located at the front in low-rise structures.

Topic Covered :

1. Introduction about Structural Drawings and Component of Structural Drawings


2. Detail Study of Foundation Drawings of Isolated Foundation, Combined Foundation, Raft Foundation

3. Details Analysis of Column Drawings from Foundation to Terrace Floor.

4. Drawing reading of Floor Beam & Slab with Section.

5. Drawing reading of Stairs & Lift with Plan & Section.

Who Can Join :

  • Civil Engineers , Structural Engineers, Structural Consultants, Architects, Civil Contractor, Real Estate Agents & Freshers those who are Intrested to learn Architectural & Structural drawings with clear understanding to Topics
  • Quantity surveyors, Project Engineer & Planning Engineers
  • Civil Engineers those who are looking for Entry Level Jobs in Design Companies
English
language

Content


Construction & Structural Drawings

Introduction
Fundamental of Structural Drawings
Structural Drawings of Column
Structural Beam Drawings
Floor Slab Drawings
